$80.87The Story
Cast Steel Globe Valve PN25/40
A handwheel operated, cast steel flanged (SDNR) globe valve with bolted bonnet, stainless steel trim and graphite packing. This Screw Down Non-Return (SDNR) globe valve prevents reverse flow when the valve is in an open position and closing the valve provides a leak-tight shut-off. Our Cast Iron Globe Valve Can be used partially open to allow for throttling flow and regulating flow pressures. The PN25/40 is an Ideal choice of valve for general-purpose applications including HVAC & Marine.
Flanged PN25/40 Ā½ā to 6ā, PN40 8ā. Cast Steel Body and Bonnet construction, Stainless Steel Disc, Stem and Seat. Graphite Packing Rated PN40 with a recommended operating temperature of -50Ā°C to +400Ā°C.
Summary:
- 40 Globe Valve
- Bolted bonnet
- Rising Stem
- Cast steel body and bonnet
- Stainless steel stem
- Graphite packing
- Hand wheel operation
- Rated PN25/40
- Operating Temperature: -50Ā° to +400Ā°C
Applications:
- Air
- Inert Gas
- Oil
- Seawater
- Steam
- Water
Specifications:
| PN rating (Pressure Nominale): | PN25/40 |
| Material: |
Cast Steel |
| Disc: | X 20Cr13 |
| Bonnet: | GP240GH+N |
| Stem: | X 20Cr13 |
| Gland: | 115MnPb30 |
| Gland Packing: | Graphite |
| Flange: | BS4504 |
| Handwheel: | EN-GJS-400-18-LT |
| Working Temperature: | -50Ā°C to +400Ā°C |
Ā
